4x4 Backhoe Loader WZ30-25

   ANSION brand new Pivot center 4X4 backhoe loader AS790 is with 7900kg operating weight and 85kw diesel engine, which is hot-selling in Brazil, Canada, Australia, Mexico, Indonesia, Saudi Arabia, Argentina, Pakistan, Chile, Bangladesh, Peru, Uzbekistan, Panama, Uruguay. Our backhoe loaders are widely applied to civil engineering works including site clearing, bulk earthworks, civil construction, roadworks, demolition and large scale electrical, plumbing and communications services, earthmoving and digging works.

SPECIFICATION

BACKHOE LOADER	AS790
Performance
Operating weight	7900 kg
Driving type	4x4
Operation type	Hydraulic pilot joystick
Dimension	7145 * 2300 * 3355 mm
Min. Turning Radius	5200 mm
Loader Performance
Rated load	2500 kg
Bucket capacity	1.3~1.5 m3
Max. Dumping height	3500 mm
Dumping reach at max. dumping height	1105 mm
Optional attachments	quick hitch, 4-in-1 multipurpose bucket,    wood grapple, pallet fork etc
Excavator Performance
Outriggers	Pivot Center
Bucket capacity	0.3 m3
Max. Digging depth	4060 mm
Max. Digging radius	5140 mm
Optional attachments	quick hitch, narrow bucket,hydraulic breaker,    auger driller etc
Engine
Brand	YUCHAI / CUMMINS
Model	4105 / 4BTA3.9-C100
Rated Power	85 Kw (115 hp)
Type	4-cylinders, water-cooling, turbocharged. diesel
Transmission
Gearbox	Countershaft Powershift
Gear shift	Forward 4 and reverse 4
Service brake	Air over oil caliper type
Tyres	16/70-20
Max. Travel speed	38 km/h
